DDR3 RDIMM VLP

DDR3 RDIMM VLP

Features:

- - Very low profile specialized for use in 1U system
  - Register that enhances clock, command, and control signals
  - ECC DIMM incorporates error correction and detection capabilities
  - Fully tested and optimized for stability and performance
  - Uses original IC to meet strict industrial standards
  - JEDEC standard 1.5V (1.425V ~ 1.575V) & 1.35V (1.28V ~ 1.45V)
  - Operating Environment: 0°C ~ 85°C
  - RoHS Compliance and CE / FCC Certification

Technical Resource

Categories: ddr3, DRAM Modules

Description
Reviews (0)

Description

Model Name	DDR3 RDIMM VLP
DDR Generation	DDR3 Memory
DIMM Type	RDIMM VLP
Speed	1333 MT/s, 1600 MT/s, 1866 MT/s
Density	4GB, 8GB
Function	Registered Memory with ECC
Pin Number	240pin
Bus Width	x72
Voltage	1.35V, 1.5V
PCB Height	0.738 Inches
Operating Temperature	0°C ~ 85°C
30μ” Gold Finger	Y

Order Information:

P/N	IC Config.	Rank	Temp.	Description
ACT4GHR72N8J1600M-VLP	512M x 8	1R x 8	0°C ~ 85°C	DDR3 1600 4GB RDIMM VLP
ACT4GHR72N8J1600M-LVP	512M x 8	1R x 8	0°C ~ 85°C	DDR3L 1600 4GB RDIMM VLP
ACT8GHR72P8J1866M-VLP	512M x 8	2R x 8	0°C ~ 85°C	DDR3 1866 8GB RDIMM VLP
ACT8GHR72P8J1866M-LVP	512M x 8	2R x 8	0°C ~ 85°C	DDR3L 1866 8GB RDIMM VLP
